GTO-15 - Tube Sign & Ignition Cable

*Product images are for illustrative purposes only and may differ from the actual product.

GTO-15 - Tube Sign & Ignition Cable

Download Spec Sheet

GTO-15 - Tube Sign & Ignition Cable

Tube Sign & Ignition Cable
GTO - 15 - 15kV
105°C - UL Listed

x



Please select all above options before adding to cart.

Construction
Category Conductor Description Stranded, bare (uncoated) annealed copper conforming to ASTM B-3 and UL Standard 814
Category Insulation Description Black, Polyvinyl Chloride (PVC)
Category Jacket Description Black, Polyvinyl Chloride (PVC)
  • Used between high voltage terminals or sign transformers and signs. Also used for oil burner ignition cable
  • UL Standard 814
  • UL TW Oil Resistant

Questions & Answers

Ask a Question

Part Number Table

Part # Houston Wire & Cable Gauge Conductors Stranding Insulation Thickness Outside Diameter Inches Material Weight (Lbs./M')
N11401-GTO 14-01GTO15 14 1 19 0.049 0.26 43

Note: The information in this specification sheet is approximate and subject to standard industry and manufacturer tolerances.  Please verify specific requirements with your Omni Cable account manager
